7006ACD Angular Contact Ball Bearing Single / Double Row Type Inner Diameter 30mm

Product Categories

Shenzhen Youmeite Bearings Co., Ltd.

Contact Now

7006ACD Angular Contact Ball Bearing Single / Double Row Type Inner Diameter 30mm

Brand Name : UMT

Model Number : 7006ACD/B7006E/7006A5

Certification : ISO9001

Place of Origin : Japan, Sweden,China

MOQ : 1 pc

Payment Terms : L/C, T/T, Western Union

Supply Ability : 200000 pcs per month

Delivery Time : 15 days

Packaging Details : According to Per Client′s Requirements

Precision Rating : P0 P6 P5 P4 P2

Model NO : 7006ACD Angular Contact Ball Bearing

Name : Angular Contact Ball Bearing

Structure : Angular Contact

Outside Diameter : 55mm

Seals Type : Open 2Z 2RS, open 2Z 2RS

Sample : Free

Contact Now

7006ACD Angular Contact Ball Bearing Single/Double Row Type Inner Diameter 30mm

Description:

Angular contact ball bearings are designed for combination radial and axial loading. Single-row bearings
have high thrust capacity in one direction. Some single-row bearings are specifically designed for duplex
mounting in sets for maximum performance. Double-row Conrad bearings can accommodate thrust in
both directions.

bearing NO.	Size			15º		25º
	Size			Limiting Speed		Limiting Speed
	ID	OD	B	Loading rating	Grease & Oil	Loading rating	Grease & Oil
	ID	OD	B	Cr Cor	Grease Oil	Cr Cor	Grease Oil
7003	17	35	10	6.7 4.9	44000 66000	6.4 4.7	39000 59000
7004	20	42	12	9.6 6.3	37000 55000	9.2 6.0	33000 49000
7005	25	47	12	12.9 8.7	33000 49000	12.3 8.3	29000 44000
7006	30	55	13	15.7 11.6	27000 42000	14.9 10.9	23000 37000
7007	35	62	14	19.3 17.5	19000 33000	10.4 10.3	19000 33000
7008	40	68	15	19.9 19.1	18000 31000	18.9 18.2	16000 27000
7009	45	75	16	26.7 25.3	16000 27000	25.4 24.1	15000 25000
7010	50	80	16	27.6 27.5	15000 25000	26.2 26.2	14000 23000
7011	55	90	18	36.7 37.1	13000 21000	34.8 35.3	12000 19000
7012	60	95	18	37.8 40	13000 21000	35.8 38	11000 18000
7013	65	100	18	38.9 42.9	12000 19000	36.8 40.7	10000 17000
7014	70	110	20	49.9 55.5	11000 18000	47.2 52.7	9000 16000
7015	75	115	20	51.3 59.2	10000 17000	48.5 56.2	8500 15000
7016	80	125	22	61.6 70.4	9000 16000	58.3 66.9	8000 14000
7017	85	130	22	63.6 75	8500 15000	59.9 71.3	7500 13000
7018	90	140	24	66.9 84	8000 14000	63.2 79.7	7000 12000
7019	95	145	24	79.1 97.6	7500 13000	74.8 92.7	6500 11000
7020	100	150	24	81.2 103.3	7000 12000	76.7 9.8	6000 10000
7021	105	160	26	93.9 118.2	6500 11000	88.8 112.2	6000 10000
7022	110	170	28	110.4 139.8	6000 10000	104.4 132.8	5700 9000
7024	120	180	28	112.7 148.7	6000 10000	106.3 141.1	5700 9000
7026	130	200	33	144.8 190.8	5700 9000	136.8 181.0	5000 8000
7028	140	210	33	148.7 202.6	5000 8000	140.4 192.2	4600 7500
7030	150	225	35	168.4 232.5	4600 7500	159.1 220.6	4000 6500

Brass Cage - 150 - + 350°C Angular contact Ball Bearing in oil hot pump:
1) Load capacities are higher than deep groove ball bearings of same dimensions
2) Used for bearing radial-axial combined loads or pure thrust loads
3) Low operating friction and high limiting speed

Specifications:

Nylon cage P4 / ABEC-7 Angular contact Ball Bearing HS71916E.T.P4S E type
Model Number	7006ACD Angular Contact Ball Bearing
Structure	Angular Contact
Type	Ball
Brand Name	UMT
Bore Size	25mm
Outside Diameter	47mm
Thickness	12mm
Net weight	0.112kg
Seals Type	Z, ZZ, RS, 2RZ, 2RS
Number of Row	single row/double Row
Place of Origin	Janpan
Material	Chrome steel, Stainless steel
Cage	Brass, Steel, Nylon
Vibration Level	V1, V2, V3
Clearance	C0, C1, C2, C3, C4, C5 etc.
Precision Rating	P0, P6, P5, P4, P2
Hardness	59-63HRC
Service	OEM or original brand
Sample available	Yes
Manufacturer	Yes
Quality guaranteed	Yes
Certificate	ISO9001:2008, ISO/TS16949
Application/Function	Automotive, truck, tractors, construction machinery
Other Service	Design service, Buyer label service
Packaging Details	Industrial Packing, Individual Boxed Packing, or OEM
Delivery Detail	2-7 days after receiving the payments or deposit

7006ACD Angular Contact Ball Bearing Single / Double Row Type Inner Diameter 30mm
