OEM open stainless ball bearings 6200 series 6300 series 6000 series zn c3

Name: OEM open stainless ball bearings 6200 series 6300 series 6000 series zn c3
Brand: UMT, SKF, NTN, FAG,KG,TIMKEN, AND SO ON
Price: 0.1 USD

Buy cheap OEM open stainless ball bearings 6200 series 6300 series 6000 series zn c3 product

Brand Name : UMT, SKF, NTN, FAG,KG,TIMKEN, AND SO ON

Model Number : 6300ZZ

Place of Origin : CHINA

MOQ : 5 pcs

Price : 0.1-10 usd /pc

Payment Terms : T/T, Western Union, MoneyGram, L/C

Supply Ability : 100000000pcs/month

Delivery Time : After receive the deposit

Packaging Details : Original package, Neutral package, single package, Wooden package+pallet, Carton package+pallet, or as customerized.

Material : Chrome steel GCr15, stanlesss

Feature : Low Noise,high precision

Bearing Precision : ABEC-5

service : OEM service

clearance : C2 C3 C4 C5 C0

samples : available

model no 6300 : 6300 ZZ

Seal : OPEN,Z,ZZ,RZ,2RZ,RS,2RS

size : 10×35×11 mm

weight : 0.053KG

Contact Now

OEM open stainless ball bearings 6200 series 6300 series 6000 series zn c3

Deep groove ball bearings has simple structure, is easy to maintenance. It is mainly used to support of axial load, and also can be used to support of radial load, has property of angle contact ball bearing, it can support large axial load. The friction coefficient is small, with high speed rating, there is variety of sizes and shapes. It is suitable for precision instrument, low noise electromotor, automobile and motorcycle, etc.

Specification

Brand	Trieternal Bearing or OEM
Name	Deep groove ball Bearing
Model	6000 Series - Extra Light Ball Bearings – Ideal for limited space applications
	6200 Series - Light Series Ball Bearings – Balanced between space and load capacity
	6300 Series - Medium Series Ball Bearings – Ideal for heavier load capacity
Material	GCr15		Certificate		ISO9001:2001
Precision	P0, P6, P5
Bore Size:	10mm-100mm	Outside diameter				25mm-220mm
Clearance	C0,C1,C2,C3,C4,C5 etc.
Cage Type	Brass cage or Stainless cage
Seals Type	ZZ,RS, 2RS, R2, Z, 2Z, 2RZ etc
Package	pallet, wooden case,industrial package or as customers' requirement
Price	FOB, CRF, CIF			Delivery Time			25-30 days
Payment Terms	A.100% irrevocable L/C at sight
	B.30% T/T in advance, 70% L/C or T/T
	C. Documents against Payment
	D. Others
Contact Details	Tel:0086-355-8502930 Fax:0086-355-3063816
	Contact person: Mr.Liu
Web	WWW.TRIETERNAL.COM
Link on Alibaba	http://te-bearing.en.alibaba.com

Deep groove ball bearing types:
1,.A single deep groove ball bearing

2. With dust cover single deep groove ball bearing

3. With dust cover, sealing ring single deep groove ball bearing outer ring, have

4. Stop moving slot and stop ring single deep groove ball bearing

5. Have put the ball of the gap of deep groove ball bearings

6. Double row deep groove ball bearing

BEARING NO	d	D	B	Kg
62201	12	32	14	0.053
62202	15	35	14	0.065
62203	17	40	16	0.096
62204	20	47	18	0.145
62205	25	52	18	0.172
62206	30	62	20	0.275
62207	35	72	23	0.410
62208	40	80	23	0.616
62209	45	85	23	0.625

Other deep groove ball bearings size

Bearing NO.	Principal dimension			Weight (Kg)	Bearing NO.	Principal dimension			Weight (Kg)
	L.D.	O.D.	Width			I.D.	O.D.	Width
6000-Z/2Z/RS/2RS	10	26	8	0.019	6214-Z/2Z/RS/2RS	70	125	24	1.04
6001-Z/2Z/RS/2RS	12	28	8	0.021	6215-Z/2Z/RS/2RS	75	130	25	1.08
6002-Z/2Z/RS/2RS	15	32	9	0.026	6216-Z/2Z/RS/2RS	80	140	26	1.38
6003-Z/2Z/RS/2RS	17	35	10	0.036	6217-Z/2Z/RS/2RS	85	150	28	1.75
6004-Z/2Z/RS/2RS	20	42	12	0.07	6218-Z/2Z/RS/2RS	90	160	30	2.18
6005-Z/2Z/RS/2RS	25	47	12	0.08	6304-Z/2Z/RS/2RS	20	52	15	0.14
6006-Z/2Z/RS/2RS	30	55	13	0.12	6305-Z/2Z/RS/2RS	25	62	17	0.22
6007-Z/2Z/RS/2RS	35	62	14	0.16	6306-Z/2Z/RS/2RS	30	72	19	0.35
6008-Z/2Z/RS/2RS	40	68	15	0.19	6307-Z/2Z/RS/2RS	35	80	21	0.42
6009-Z/2Z/RS/2RS	45	75	16	0.24	6308-Z/2Z/RS/2RS	40	90	23	0.63
6010-Z/2Z/RS/2RS	50	80	16	0.28	6309-Z/2Z/RS/2RS	45	100	25	0.83
6011-Z/2Z/RS/2RS	55	90	18	0.38	6310-Z/2Z/RS/2RS	50	110	27	1.08
6012-Z/2Z/RS/2RS	60	95	18	0.41	6311-Z/2Z/RS/2RS	55	120	29	1.37
6013-Z/2Z/RS/2RS	65	100	18	0.43	6312-Z/2Z/RS/2RS	60	130	31	1.71
6014-Z/2Z/RS/2RS	70	110	20	0.6	6313-Z/2Z/RS/2RS	65	140	33	2.09
6015-Z/2Z/RS/2RS	75	115	20	0.64	6314-Z/2Z/RS/2RS	70	150	35	2.6
6016-Z/2Z/RS/2RS	80	125	22	1.05	6315-Z/2Z/RS/2RS	75	160	37	3
6017-Z/2Z/RS/2RS	85	130	22	1.1	6316-Z/2Z/RS/2RS	80	170	39	3.62
6018-Z/2Z/RS/2RS	90	140	24	1.16	6317-Z/2Z/RS/2RS	85	180	41	4.27
6019-Z/2Z/RS/2RS	95	145	24	1.21	6404-Z/2Z/RS/2RS	20	72	19	0.4
6020-Z/2Z/RS/2RS	100	150	24	1.25	6405-Z/2Z/RS/2RS	25	80	21	0.51
6204-Z/2Z/RS/2RS	20	47	14	0.1	6406-Z/2Z/RS/2RS	30	90	23	0.72
6205-Z/2Z/RS/2RS	25	52	15	0.12	6407-Z/2Z/RS/2RS	35	100	25	0.82
6206-Z/2Z/RS/2RS	30	62	16	0.19	6408-Z/2Z/RS/2RS	40	110	27	1.16
6207-Z/2Z/RS/2RS	35	72	17	0.27	6409-Z/2Z/RS/2RS	45	120	29	1.55
6208-Z/2Z/RS/2RS	40	80	18	0.37	6410-Z/2Z/RS/2RS	50	130	31	1.91
6209-Z/2Z/RS/2RS	45	85	19	0.42	6411-Z/2Z/RS/2RS	55	140	33	2.3
6210-Z/2Z/RS/2RS	50	90	20	0.47	6412-Z/2Z/RS/2RS	60	150	35	2.8
6211-Z/2Z/RS/2RS	55	100	21	0.58	6413-Z/2Z/RS/2RS	65	160	37	3.35
6212-Z/2Z/RS/2RS	60	110	22	0.77	6414-Z/2Z/RS/2RS	70	180	42	4.6
6213-Z/2Z/RS/2RS	65	120	23	0.98	6415-Z/2Z/RS/2RS	75	190	45	5.69

Packaging:
A: barreled package+outer carton+pallets
B: single box+outer carton+pallets
C: tube package+middle box+outer carton+pallets
D: According to your requirement
Delivery:
A:Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
B:Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
C:More than 200 KGS, we will send by sea. ( Cheapest, but long time )

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 3-20 days if the goods are in stock. or it is 5-30 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
